M-Audio BX Subwoofer Speaker

Features

• 10” long-excursion low-frequency driver with oversized magnet

• 240-watt Class A/B amplifier with all-discrete transistor design

• Stereo inputs: XLR; 1/4" balanced/unbalanced; RCA

• Stereo satellite outputs: XLR; 1/4" balanced/unbalanced

• Internal crossover offers variable frequency

• Included subwoofer bypass footswitch

• High-density bass reflex cabinet with internal bracing

• Removable grill and detachable feet

• 180 phase reverse switch

Specifications

• Type: Bass-reflex active powered subwoofer

• Woofer Driver: 10-inch composite (treated paper/fiberglass) cone with high-temperature voice coil and damped rubber surround

• Frequency Response: 20-200Hz (-3dB)

• Crossover: HP/LP linked filter sweepable from 50-200Hz; 24dB/octave 4th-order alignment

• Input Sensitivity: 80mV pink noise input produces 100dBA output SPL at one meter with vol

• Adjustable Gain: (-30dB to +6dB)

• Amplifier: 240 watts average power into 4, discrete transistor design

• Signal-To-Noise Ratio: 96dB (A-weighted)

• THD at Rated Power, Mono Mode: 0.019%

• Inputs: Two XLR balanced/unbalanced inputs; two TRS balanced/unbalanced inputs; two unbalanced RCA

• Outputs: Two XLR balanced/unbalanced outputs for satellites; two TRS balanced/unbalanced outputs for satellites

• Controls: Volume/gain control, phase inverse switch, variable crossover control, subwoofer bypass footswitch jack

• Input Impedance: 20k ohms balanced, 10k ohms unbalanced

• Maximum Input Level: +20dBU

• Protection: Over temperature, turn-on/off transient, subsonic filter, external mains fuse, DC protection, over current protection

• Indicator: Power on (blue) or standby/bypass (red)

• Power Requirements: Dual-voltage (selectable by rear-panel switch) for either 100-120V/~50/60Hz or 220-240V/~50/60Hz; powered via detachable grounded IEC cable

• Cabinet: Vinyl-laminated high-density internally braced 3/4” MDF cabinet with 1” front and back baffles

• Dimensions: 15.5 in. (h) x 13 in. (w) x 17.25 in. (d); 39.4 cm (h) x 33 cm (w) x 43.8 cm (d)

• Shipping Weight: 54.6 lbs.; 24.75 kg
